ANTBOX N5 – Independent Mining Farm

Popular Antbox N5 Mining Server S17 T17 series miner is 180 units Container with Power Supply …  20feet Mobile Container Mining Farm S19 CSA CE.

Bitmain has pulled out all the stops and packed with features that help miners achieve industry crushing hashrates.

ANTBOX N5
Product description	Specifications
Version	ANTBOX N5
Overall dimensions (L,W, H) (mm)	6058*2438*2896
Miner capacity	17 series miner is 180 units
Container certification	China Classification Society Certification
Safety certificate	Power distribution cabinet, PDUs, cables, switches, network cables, etc are certified by UL/CUL.
Operating power (KW)	658
Voltage Input and frequency	380V~415V AC 50~60HZ
Detailed specifications	Specifications
Overall weight (ton, excluding miner)	3.8
Main switch of power distribution cabinet (A)	1200
Rated current (A)	1000
Standard power (KW)	658
Maximum power (KW)	719
Single PDU rated current (A)	31
Single unit rated current (A)	18
Single socket rated current (A)	9
2500KVA transformer can bring Antbox quantity	4
Snow load (KN/㎡)	3.5
Configuration	QTY
Power Distribution Cabinet（PDC）	1
PDC to PDU  power cable	30
PDU	30
Miner power cable	360
Switch	15
Network cable	180
Rack	3
Water curtain	2
